Construction

Built at Southern Cape Yachtbuilders and launched in September of 2010. Hulls, decks, pilot house and major bulkheads are constructed from epoxy resin and tri-axial glass laminate cored with Herex PVC marine grade foam. All exterior surfaces are spray painted with AwlGrip™ polyurethane coating. Some Alexseal polyurethane used post construction for its re-finish properties. Crossbeams are built of uni-directional carbon fiber/epoxy with foam cored epoxy/glass bulkheads.

Engines and Mechanical Systems

Engines were replaced May 2019 under Volvo recall due to EPA certification issues. Engine rooms are aft in each hull with a large hatch and ladder for easy entry and egress. Full stand up space with good lighting and easy access to systems. The port engine room contains the Diesel Furnace and water heater, which is plumbed to both engines to scavenge heat when underway. The starboard engine room contains 125-volt and 230-volt shore power breakers and isolators, cable winch for davit, autopilot, and AIS transceiver.

Sails

Fully Battend Mainsail and Roller Furling Jib are FiberPath Enduro Voyager Series, from Ullman Sails, New in 2022. Screecher is Cuben Fibre from North Sails, worn but still of good service. Asymmetrical Spinnaker with sock is made of Norlon and in good condition. And there is also a Dacron Storm Sail in excellent condition.

Sail Area
Mainsail: 860 sq/ft
Jib: 430 sq/ft
Stormsail: 107 sq/ft
Code 0: 1075 sq/ft
Asym.Spinnaker 1940 sq/ft

Rig

Mast and Boom
Carbon fibre mast, deck stepped with stainless steel diamonds over carbon fibre spreader
Masthead light, masthead WiFi, wind instruments
All halyards and reefing lines are led to cockpit
Carbon fibre boom with internal main sheet and reefing lines
Karver furler for screecher
Standing Rigging:
Capshrouds by Future Fibres K49 Kevlar 25T
Lowers by Future Fibres K49 Kevlar 15T
Forestay new with roller furler
Martingale 316 Dyform 14mm SS wire
Inner Forestay 12mm Dynex
Running Rigging:
Ultra low-stretch Dyneema lines for halyards, sheets, and preventers (New 2022), and low-stretch Spectra reefing lines

Electrical

Primary circuits for winches, autopilot, lighting, refrigeration, pumps, fans, etc. are 24-volt DC and controlled by the CZone Touch10 Display/Control Panel and Digital Switch NMEA 2000 Network (New 2021). This new system also offers onboard wireless monitor and control through your smart device and remote monitor and control of some circuits via Siren Marine Monitor via the internet. Additional 24-volt and 12-volt circuits are controlled at the Blue Seas Breaker Panels in the workshop Electrical Panel. The 24-volt system is charged by solar panels on the cabin top, high output alternators on both engines, and either 125-volt 60Hz, or 230-volt 50Hz shore power.

There are now two, separate, alternating current systems onboard: The original “Euro-style” 230-volt 50Hz system, with Mastervolt Inverter/Charger, shore power connections, isolator, inlet breaker, distribution panel with circuits and 230-volt outlets, remains. And a complete, new, 125-volt 60Hz system with Inverter/Charger shore power connections, isolator, inlet breaker with distribution panel, circuits and 125-volt outlets has been installed. Each system supplies its respective voltage to a network of outlets and circuits throughout the vessel. Power comes from shore connections or, from the 24-volt House battery bank, via either inverter. This gives the operator the option to plug into shore power around the globe (230 50Hz and 125 60Hz) and operate appliances on either voltage onboard via the inverters and network of outlets. The IsoTherm electric water heater is currently configured for 125-volt service; in the event the vessel travels to a 230-volt 50Hz geographic zone, it would require the heating element to be switched back to the 230-volt. 230-volt circuit and heating element are existing and aboard.

Electrical Equipment:

•    CZone Touch10 Display/Control Panel with NMEA 2000 Digital Switching Network
•    24-volt circuit breakers controlled from CZone Touch 10 Control Panel and/or wireless smart device
•    Mastervolt 230-volt 50Hz Inverter/Charger
•    Mastervolt 125-volt 60Hz Inverter/Charger
•    Batteries: Four 200 Amp-hour at 12-volts gel batteries, (NEW 2021).
•    Separate AGM engine start batteries for each engine
•    4 Solar Panels, 205 watt output each
•    Each engine has 2 alternators. 1 for the starter battery and 1 high output Mastervolt 24/95C (95Amp) Alpha alternator for the house batteries
•    Siren Marine Monitor, for remote monitoring of critical systems
•    LED lighting throughout

Full Disclosure:
- It is believed that the 230-volt 50Hz inverter has been damaged by attempts to power it with 240-volt 60Hz (US shore power). It is advised to inspect and likely repair or replace this 230-volt 50Hz inverter before traveling to a 230-volt 50Hz region and connecting to shore power.
- There is a wind generator installed but inoperable. It should be removed, repaired, or replaced.

Electronics Package

The navigational electronics package is a little dated, but it is a robust, full featured, and durable installation. The NKE Marine Electronics package will be a treat for Racers and Performance Sailors. Dependable sensors with updated display and processor provide for features such as up to six autopilot modes, including True Wind and Apparent Wind Rudder (keeps course relative to wind direction). The 14’ touch screen Furuno MFD provides the operator with all the information and graphics that one could desire. Recently added features offer the ability to view and control your navigation instruments such as the autopilot and chart plotter, via your smart device. You can also monitor and control certain onboard systems remotely via the internet. Inquire about pending updates to this package.

• Chartplotter: Furuno TZT14 NavNet 14.1” color LCD Multifunction
• Radar: Furuno DRS4D 24” x 4 kW Ultra High Definition Digital Radome on post at stern.
• GPS: Furuno GP330B WAAS GPS receiver/Antenna
• AIS: Furuno FA-50 AIS Class A/B (transmit and receive) with dedicated GPS
• VHF: ICOM M502 display/mic (helmstation stbd for pilothouse.)
• VHF Handheld: new handheld
• Cellular Data: KVH LTE-1 with wireless router
• Compass: Danforth 4” C402D Hi-Speed compass
• NKE wind-speed/wind-direction masthead sensors (New 2021)
• NKE ultrasonic speed and depth sensors
• NKE fluxgate compass
• NKE Gyropilot Graphic in pilothouse
• NKE autopilot
• NKE Multidisplay unit in cockpit, visible from pilothouse (New 2022)
• NKE Pad Pilot on cockpit steering pedestal. (New 2022)
• NKE GyroPilot remote control (New 2022)
• NKE new wireless transceiver for remote and smart devices
• NKE to NMEA 2000 converter and associated hardware aboard to convert the small NKE / Furuno network to NMEA 2000 (New 2022)
• Data Hub, to be incorporated into the NMEA 2000 network above (New 2022)
• Iridium Go satellite phone with messaging and data services (New 2022)
• Digital Barometer

General Deck and Mechanicals

Deck Hardware:
Anderson Stainless Steel self-tailing winches:
1 electric #46 for jib sheet/main halyard
2 x #52 (one electric 2002) for main sheet, screecher / spinnaker sheets and preventer
Harken CB Big Boat main sheet traveler
Harken jib sheet track
SS A-frame davit with 12-volt winch, Dynema line and two wireless remote for lift assist.

Hull and Deck Ventilation:
16 Deck hatches, all Lewmar Ocean Series. Accommodation area hatches are equipped with roller shade/screens.
Eight opening portlights with clear plexi windows, three in each outboard hull side and one adjacent to each double berth
Cowl vents forepeaks, heads, galley and shower.
10 Caframo Bora fans, throughout the interior help to circulate plenty of fresh air.
Bug Screen Enclosure for the aft deck
Canvas Shade Covers for Cockpit; Side Decks; and Aft Deck

Rails and Lifelines:
Custom fabricated SS stanchions and lifelines
Custom fabricated polished SS pushpits
4 SS Transom grab rails
Integral swim step on rudder

Anchor Handling:
Dual bow anchor rollers enable two anchors to be easily used at the same time
Maxwell, RC10 1200W windlass with rope/chain gypsy and dual direction switch
Self-bailing lockers for self stowing chain and rode

Ground Tackle:
Two anchors and rodes. Primary anchor is a 70lb. Lewmar Delta Anchor with 165’ of 3/8” BBB
chain and 165’ 5/8” nylon rode
The second anchor is a Fortress 21lb with 16' chain and 330' 5/8" nylon rode

Cleats and Docklines:
8 12" docking cleats, 2 bow, 2 stern, 4 springline
2 10” mooring cleat
16mm docking lines
Navigation Lights
Hella LED masthead Tri-color and anchor light
Mast mounted steaming light
Hella NaviLED deck level running lights
Aft deck floodlight and sternlight

Tanks:
2 Moeller FT8008 80 gallon diesel fuel tanks each with deck fill, shut off and gauge
2 integral Epoxy/glass 40 gallon water tanks, each with deck fill, vent, gauge and inspection window

Heating:
Webasto 5kW diesel furnace, with recirculating hot air. (Full Service 2022)

Interior details by area of the Yacht.
